רסיבר קולנוע ביתי מבית ONKYO דגם TX-NR7100

פרטים תכנים:

Power output (All channels)
220 W/Ch (6 ohms, 1 kHz, 10% THD,1-ch driven) 100 W/Ch (8 ohms, 20 Hz–20 kHz, 0.08% THD, 2-ch driven, FTC)
Dynamic power
250 W (3 ohms, Front) 220 W (4 ohms, Front) 130 W (8 ohms, Front)
THD+N (Total Harmonic Distortion + Noise)
0.08% (20 Hz–20 kHz, half power)
Input sensitivity and impedance
200 mV rms/47 k-ohms (Line) 3.5 mV rms/47 k-ohms (Phono MM)
Rated RCA output level and impedance
1 V rms/470 ohms (Subwoofer pre-out) 200 mV rms/470 ohms (Zone 2/Zone B line-out)
Frequency response
10 Hz–100 kHz/+1 dB, -3 dB (Direct/Pure Audio)
Tone control
±10 dB, 20 Hz (Bass) ±10 dB, 20 kHz (Treble)
Signal-to-noise ratio
106 dB (Line, IHF-A) 80 dB (Phono, IHF-A)
Speaker impedance
4–16 ohms

FM
87.5 MHz–107.9 MHz
AM
530 kHz–1,710 kHz
FM/AM preset memory
40 stations
Power supply
AC 120 V~, 60 Hz
Power consumption (operating)
750 W
Power consumption (idle)
75 W
Power consumption (standby)
0.1 W

מידות

– גובה: 17.3 ס"מ
– רוחב: 43.5 ס"מ
– עומק: 37.9 ס"מ
– משקל: 10.4 ק"ג
